NEMA 3R, 4X, 4X/7 Combination Motor Starters and Circuit Breaker with Enclosure Data Sheet

IPE Engineering Practice IPE-EP-13-7-2DS

Document number: IPE-EP-13-7-2DS · Section: 13 — Electrical

IV. NAME PLATE SCHEDULE PER PARAGRAPH 5.5	IV. NAME PLATE SCHEDULE PER PARAGRAPH 5.5	IV. NAME PLATE SCHEDULE PER PARAGRAPH 5.5	IV. NAME PLATE SCHEDULE PER PARAGRAPH 5.5	IV. NAME PLATE SCHEDULE PER PARAGRAPH 5.5
UNIT NO.	LINE ONE	LINE TWO	LINE THREE	LINE FOUR

V. DOCUMENTATION	V. DOCUMENTATION	V. DOCUMENTATION	V. DOCUMENTATION	V. DOCUMENTATION
INFORMATION	WITH QUOTATION	WITH QUOTATION	(FOR APPROVAL) AFTER RECEIPT OF ORDER	FINAL / CERTIFIED
THREE LINE DIAGRAM
ELEMENTARY DIAGRAM
ENCLOSURE OUTLINE INCLUDING CONDUIT LOCATION/SIZES
OVERLOAD HEATER TYPE AND MODEL NUMBER
INDICATE IF EQUIPMENT IS UL LISTED,UL CLASSIFIED, OR NON-UL LISTED / CLASSIFIED
UNIT AIC AS UL LISTED OR UL CLASSIFIED
COORDINATION CURVES FOR PROTECTIVE DEVICES
MANUALS: INSTALLATION, MAINTENANCE, OPERATION
OTHER:
DRAWING AND DOCUMENT QUANTITIES FOR ITEMS IN INFORMATION SECTION :
-- WITH QUOTATION
-- FOR APPROVAL -- FINAL CERTIFIED -- MANUALS: INSTALLATION,	COPIES COPIES COPIES	REPRO REPRO REPRO	REPRO REPRO REPRO
MAINTENANCE, OPERATION
	COPIES	REPRO	REPRO
